Leofoto Juggernaut Head

New Release

The Juggernaut Head sets a new benchmark for all-in-one rifle support, engineered for any tactical or hunting applications.

Built around a large 40mm ball structure, the Juggernaut delivers exceptional locking strength while maintaining a compact, low-profile design. The result is rock-solid stability with silky-smooth operation and precise control.

Independent controls for each mounting standard ensure optimal performance across platforms. A fine-adjustment lever allows precise tensioning of Arca rails, while a dedicated Picatinny locking knob provides uncompromising retention.

Once mounted to the tripod, six integrated set screws can be tightened using the included Allen wrench stored in the side pocket,  to maximize stability and recoil resistance in demanding shooting conditions.

Key Features

• Hybrid Arca–Picatinny Dual-Rail Clamp – Seamlessly supports both mounting standards with independent controls
• 40 mm Ball – Increased mass and surface area for superior locking power
• Low-Profile Design – Keeps rifle height minimal while maintaining full adjustability
• Ultra-Smooth Rotation – Comparable to premium precision rifle heads
• Fine-Adjustment Arca Lever – Dial in perfect clamp tension
• Dedicated Picatinny Locking Knob – Secure, repeatable Pic rail engagement
• Six Security Set Screws – Tighten after installation for maximum rigidity

Specifications

• Ball Diameter: 40 mm / 1.57 in
• Maximum Load Capacity: 20 kg / 44.09 lb
• Mounting Thread: 3/8"-16
• Weight: 491 g / 1.08 lb
• Height: 83 mm / 3.27 in
• Base Diameter: 57 mm / 2.24 in
