2024 NEW PRODUCT
The Leofoto SA-X Series tripods are one of the most compact collapsed setups on the market with a perfectly balanced weight to strength ratio. The "X" version has a newly designed apex with a rosette connector for SA-X rifle heads AND a 3/8" mounting screw to attach any standard 3/8" head. The rosette connector provides an extremely stable connection between the tripod's apex and the base of the head. The angle stop design has also been improved from the standard pull tab to a knurled bar which allows the user to adjust the angles with only one hand as opposed to two. The SA-X Series offers unparalleled versatility, built as a hunter’s companion who also enjoys long days on the range, but most requested by military, law enforcement, competitive shooters or those simply looking for one of the most compact and reliable shooting supports on the market. The SA-X Series tripods offer maximum rigidity, capable of supporting non-traditional shooting positions with a heavy load capacity. These tripods feature three angle stop positions to increase shooting capabilities and a compact design which maintains a small footprint, creating a tripod setup which is extremely easy to pack and carry on the go.
-
New "X" Version Apex Design: Rosette Connector AND 3/8" Mounting Stud
- New "X" Version Angle Stop: Allows for one handed angle adjustment
- Threaded 1/4” accessory socket on the side of the apex to provide the perfect placement of a strap or magic arm for holding anything from an umbrella, phone or even a kestrel
- Tripods must occasionally withstand tremendous bending and torsion loads. It is crucial that the leg angle stops and all other structural joints are well supported. Leofoto offset leg joints fully support the leg angle stops allowing loads to be transferred straight through the strongest members of the tripod. This also means the tripod is more compact when collapsed
- Large diameter rubber feet keep leg sidewalls from touching the ground even at the lowest settings and makes positive contact with the ground at virtually any angle
- Hard anodized, CNC-machined 6061 T6 aluminum hardware
- Toray Carbon Fiber Leg Tubes
- Included: Leofoto Tripod Case
The Leofoto MA-40X Lever-Release Rapid Lock Ball Head was designed specifically to be used on an SA-X tripod, but it features both the SA-X rosette connection as well as a standard 3/8" mounting socket. The head has a lever release to lock/unlock the ball and a redesigned lever-release clamp system with an adjustable clamping width.
*The Leofoto SA-X series tripods use a new mounting system that can accept both SA-X specific rosette mounting heads as well as any standard 3/8" compatible head.
*Two versions are available: one with a dual Arca and Picatinny clamp and another with an Arca-only clamp. Please choose the option that best suits your needs.
SA-324CX+MA-40X |
Rosette + 3/8” X Angle Stops Tubes: 32/28/25/22mm With head |
Max. height: 1530mm / 60.24in Min. height: 176mm / 6.92in Folded length: 613mm / 24.13in Leg Section : 4 Weight: 1.84kg / 4.06lb Max load: 25kg / 55.12lb |
SA-324CLX+MA-40X |
Rosette + 3/8” X Angle Stops Long ver. Tubes: 32/28/25/22mm With head |
Max. height: 1725mm / 67.91in Min. height: 187mm / 7.36in Folded length: 664mm / 26.14in Leg Section : 4 Weight: 1.91kg / 4.21lb Max load: 25kg / 55.12lb |
SA-364CX+MA-40X |
Rosette + 3/8” X Angle Stops Tubes: 36/32/28/25mm With head |
Max. height: 1625mm / 63.98in Min. height: 173mm / 6.81in Folded length: 657mm / 25.86in Leg Section : 4 Weight: 2.21kg / 4.87lb Max load: 30kg / 66.14lb |
SA-363CX+MA-40X |
Rosette + 3/8” X Angle Stops Long ver. Tubes: 36/32/28mm With head |
Max. height: 1683mm / 66.26in Min. height: 188mm / 7.4in Folded length: 786mm / 30.94in Leg Section : 3 Weight: 2.20kg / 4.85lb Max load: 35kg / 77.16lb |
SA-402CX+MA-40X |
Rosette + 3/8” X Angle Stops Tubes: 40/36mm With head |
Max. height: 1618mm / 63.7in Min. height: 205mm / 8.07in Folded length: 1004mm / 39.53in Leg Section : 2 Weight: 2.39kg / 5.27lb Max load: 50kg / 110.234lb |
SA-403CX+MA-40X | Rosette + 3/8” X Angle Stops Tubes: 40/36/32mm With head |
Max. height: 1573mm / 61.9in Min. height: 180mm / 7.08in Folded length: 754mm / 29.69in Leg Section : 3 Weight: 2.48kg / 5.47lb Max load: 50kg / 110.234lb |
SA-404CLX+MA-40X | Rosette + 3/8” X Angle Stops Long ver. Tubes: 40/36/32/28mm With head |
Max. height: 1815mm / 71.46in Min. height: 179mm / 7.05in Folded length: 719mm / 28.3in Leg Section: 4 Weight: 2.70kg / 5.95lb Max load: 40kg / 88.18lb |
