2024 NEW PRODUCT
The Leofoto SA-X Series tripods are one of the most compact collapsed setups on the market with a perfectly balanced weight to strength ratio. The "X" version has a newly designed apex with a rosette connector for SA-X rifle heads AND a 3/8" mounting screw to attach any standard 3/8" head. The rosette connector provides an extremely stable connection between the tripod's apex and the base of the head. The angle stop design has also been improved from the standard pull tab to a knurled bar which allows the user to adjust the angles with only one hand as opposed to two. The SA-X Series offers unparalleled versatility, built as a hunter’s companion who also enjoys long days on the range, but most requested by military, law enforcement, competitive shooters or those simply looking for one of the most compact and reliable shooting supports on the market. The SA-X Series tripods offer maximum rigidity, capable of supporting non-traditional shooting positions with a maximum load capacity ranging from 33 pounds to 55 pounds fully extended. These tripods feature three angle stop positions to increase shooting capabilities and a compact design which maintains a small footprint, creating a tripod setup which is extremely easy to pack and carry on the go.
-
New "X" Version Apex Design: Rosette Connector AND 3/8" Mounting Stud
- New "X" Version Angle Stop: Allows for one handed angle adjustment
- Threaded 1/4” accessory socket on the side of the apex to provide the perfect placement of a strap or magic arm for holding anything from an umbrella, phone or even a kestrel
- Tripods must occasionally withstand tremendous bending and torsion loads. It is crucial that the leg angle stops and all other structural joints are well supported. Leofoto offset leg joints fully support the leg angle stops allowing loads to be transferred straight through the strongest members of the tripod. This also means the tripod is more compact when collapsed
- Large diameter rubber feet keep leg sidewalls from touching the ground even at the lowest settings and makes positive contact with the ground at virtually any angle
- Hard anodized, CNC-machined 6061 T6 aluminum hardware
- Toray Carbon Fiber Leg Tubes
- Included: Leofoto Tripod Case
The Leofoto MG-40X Lever-Release Rapid Lock Ball Head was designed specifically to be used on an SA-X tripod, but it features both the SA-X rosette connection as well as a standard 3/8" mounting socket. The head has a large knurled, knob control, to lock/unlock the ball and a redesigned lever-release clamp system with an adjustable clamping width.
*The Leofoto SA-X series tripods use a new mounting system that can accept both SA-X specific rosette mounting heads as well as any standard 3/8" compatible head.
*Two versions are available: one with a dual Arca and Picatinny clamp and another with an Arca-only clamp. Please choose the option that best suits your needs.
SA-324CX+MG-40X |
Rosette + 3/8” X Angle Stops Tubes: 32/28/25/22mm With head |
Max. height: 1541mm / 60.67in Min. height: 192mm / 7.56in Folded length: 625mm / 24.6in Leg Section : 4 Weight: 1.96kg / 4.32lb Max load: 25kg / 55.12lb |
SA-324CLX+MG-40X | Rosette + 3/8” X Angle Stops Long ver. Tubes: 32/28/25/22mm With head |
Max. height: 1742mm / 68.58in Min. height: 202mm / 7.95in Folded length: 680mm / 26.77in Leg Section : 4 Weight: 2.03kg / 4.48lb Max load: 25kg / 55.12lb |
SA-364CX+MG-40X | Rosette + 3/8” X Angle Stops Tubes: 36/32/28/25mm With head |
Max. height: 1636mm / 64.41in Min. height: 185mm / 7.28in Folded length: 667mm / 26.26in Leg Section : 4 Weight: 2.34kg / 5.16lb Max load: 30kg / 66.14lb |
SA-363CX+MG-40X | Rosette + 3/8” X Angle Stops Long ver. Tubes: 36/32/28mm With head |
Max. height: 1700mm / 66.93in Min. height: 200mm / 7.87in Folded length: 800mm / 31.49in Leg Section : 3 Weight: 2.33kg / 5.14lb Max load: 35kg / 77.16lb |
